We have a wide range of tooling solutions to support quality tube fabrications and custom engineering

See our full list of all diameters and radius. Other sizes are available – please contact us if you have any requirements not listed.

Tube Diameter

DiameterBend Radii
4mm5mm, 16mm, 22mm
4.75mm12.55mm
6mm10mm, 15mm, 18mm, 20mm, 25mm, 40mm
8mm13.5mm, 18mm, 20mm, 25mm, 30mm, 40mm
9.53mm13.5mm, 18mm, 20mm, 25mm, 30mm, 40mm
10mm20mm, 25mm, 27.5mm, 35mm
12mm20mm, 30mm, 60mm
12.7mm19mm, 25mm, 30mm, 31.75mm, 40mm, 46.5mm, 50mm, 66mm, 75mm, 90mm, 125mm
14mm25mm, 30mm, 35mm, 40mm
DiameterBend Radii
15mm30mm, 35mm, 38mm, 50mm, 65mm, 67mm, 100mm
15.88mm25mm, 30mm, 32mm, 35mm, 39mm, 45mm, 50mm, 58mm, 60mm, 65mm, 70mm, 75mm, 87.5mm, 90mm, 100mm, 120mm, 139mm, 150mm, 163mm
18mm25mm, 27mm, 30mm, 35mm, 38mm, 40mm, 45mm, 70mm, 120mm, 150mm
19.05mm40mm, 50mm, 67mm, 76mm, 95mm, 102mm, 150mm
20mm30mm, 40mm, 45mm, 50mm, 60mm, 76mm, 80mm, 190mm
22mm40mm, 50mm, 55mm, 60mm, 100mm, 128mm, 190mm
22.2mm40mm, 50mm, 60mm, 63mm, 75mm, 78mm, 100mm, 116mm, 119mm, 125mm, 144mm, 145mm
25.4mm40mm, 50mm, 52mm, 60mm, 62.7mm, 76mm, 100mm, 120mm, 150mm, 170mm, 180mm
28.6mm50mm, 60mm, 65mm, 70mm, 90mm, 100mm
DiameterBend Radii
30mm50mm, 55mm, 70mm, 90mm, 100mm
31.75mm60mm, 65mm, 70mm, 80mm, 100mm, 135mm
33.7mm95mm
35mm55mm, 67.5mm, 75mm, 85mm, 120mm, 160mm
38.1mm70mm, 80mm, 95mm, 100mm, 113mm, 120mm, 225mm
40mm100mm, 200mm
44.45mm80mm
50mm75mm, 100mm
50.8mm75mm, 100mm, 150mm, 250mm
Tube sizeCentre Line Radius
4mm5mm, 16mm, 22mm
4.75mm12.5mm
6mm10mm, 15mm, 18mm, 20mm, 25mm, 40mm
8mm13.5mm, 16mm, 18mm, 20mm, 25mm, 30mm, 35mm, 40mm, 42mm, 50mm
9.53mm18mm, 20mm, 23.5mm
10mm20mm, 25mm, 27.5mm, 30mm, 35mm, 50mm
12mm20mm, 30mm, 50mm, 60mm
12.7mm19mm, 25mm, 30mm, 31.75mm, 40mm, 46.5mm, 50mm, 66mm, 75mm, 90mm, 125mm
14mm25mm, 30mm, 35mm, 40mm
15mm24mm, 30mm, 35mm, 38mm, 50mm, 65mm, 67mm, 100mm
15.88mm25mm, 30mm, 32mm, 35mm, 39mm, 45mm, 50mm, 58mm, 60mm, 65mm, 70mm, 75mm, 87.5mm, 87.5mm, 90mm, 100mm, 120mm, 139mm, 150mm, 163mm
18mm25mm, 27mm, 30mm, 38mm, 40mm, 45mm, 82mm, 70mm, 120mm, 150mm
19.05mm35mm, 40mm, 45mm, 50mm, 67mm, 76mm, 95mm, 102mm, 150mm
20mm30mm, 40mm, 45mm, 50mm, 60mm, 76mm, 80mm, 110mm, 150mm, 190mm
21.3mm50mm
22mm40mm, 50mm, 55mm, 60mm, 100mm, 128mm
22.2mm40mm, 50mm, 60mm, 63mm, 75mm, 78mm, 100mm, 116mm, 119mm, 125mm, 144mm, 145mm
25.4mm40mm, 50mm, 52mm, 60mm, 62.7mm, 76mm, 82mm, 100mm, 120mm, 150mm, 170mm, 180mm
28.6mm50mm, 60mm, 65mm, 70mm, 90mm, 100mm
30mm50mm, 55mm, 70mm, 75mm, 90mm, 120mm
31.75mm60mm, 65mm, 70mm, 80mm, 100mm, 135mm
33.7mm50mm, 95mm
35mm55mm, 67.5mm, 75mm, 85mm, 120mm, 160mm, 170mm
38.1mm70mm, 80mm, 95mm, 100mm, 113mm, 120mm, 225mm
40mm100mm, 130mm, 200mm
44.45mm80mm
50mm100mm
50.8mm100mm, 150mm, 190mm, 250mm
